QX型西洋参切片机

 提示：点击图片可以放大
QX型西洋参切片机

QX型西洋参切片机主要用途：

QX型西洋参切片机又称高效气压式切片机，是公司新自行设计的专利产品，是中药饮片加工的关键设备之一，主要为切制西洋参，鹿茸、天麻等参类药材。


QX型西洋参切片机主要原理：

药材装入装料桶，放入置料器中，由气缸匀速送到切片刀刀口进行切制；机架上设有二个置料器；由各自的气缸送料。两个气缸分别设有下降、上升二个开关单独控制工作；切片厚薄的调整由调节钉来控制、调节；

QX type Panax quinquefolium slicer is mainly used for:

QX type Panax quinquefolium slicer, also known as high efficiency pneumatic slicer, is a patent product newly designed by the company. It is one of the key equipment for processing Chinese herbal pieces, mainly for cutting Panax quinquefolium, pilose antler, Gastrodia elata and other ginseng medicinal materials.

The main principle of QX type Panax quinquefolium slicer is as follows

The medicinal materials are loaded into the loading barrel, put into the feeder, and sent to the edge of the slicing knife by the air cylinder at a constant speed for cutting; The machine frame is provided with two feeding devices; Feeding by respective cylinder. The two cylinders are respectively provided with two switches for descending and ascending to control the operation independently; The adjustment of slice thickness is controlled and adjusted by adjusting screw;


QX型西洋参切片机技术参考（Technical reference of QX type Panax quinquefolium slicer）：

  •  型号



    切片厚度

    （mm）



    进料口尺寸

    （mm）



    参考产量

    （Kg/h）



    功率/电压

    （KW/V)

    		电机型号  切刀频率



    外型尺寸

    （M)



    重量（KG)

     QXP-600.2-2.5 ＜60 20-150 0.55/380 Y801-4 1200 0.35×0.52×1.16 80
