SCT系列物料提升机

 提示:点击图片可以放大

STC系列物料输送机主要用途:用于药材、饮片提升与过程输送。

STC系列物料输送机主要特点:该机采用食品级输送带,符合GMP要求。下置传动机构,重心低,运行稳定、可靠。可移动式提升机型适合用"SCTY "表。

The main purpose of STC series material conveyors is to improve the processing of medicinal materials, slices and processes.


STC series material conveyor main features: the machine adopts food grade conveyor belt, in line with GMP requirements. The lower drive mechanism has low center of gravity, stable and reliable operation. The removable hoist model is suitable for using the "SCTY" table.


STC系列物料提升机技术参考:

  •  型号

    提升高度

    (mm)

    输送能力

    (kg/h)

     功率/电压

    (kw/v)

     重量

    (kg)

     外型尺寸

    (M)

     SCT-120/300 1200 200-800 0.25/380 60 1.5*0.6*1.7
     SCT-160/300 1600 200-800 0.25/380 70 1.8*0.6*2.0
     SCT-180/300 1800 200-800 0.25/380 80 1.9*0.6*2.2
     SCT-120/400 1200 350-1200 0.25/380 70 1.5*0.8*1.7
     SCT-160/400 1600 350-1200 0.25/380 80

     1.8*0.8*2.0
